1120014

E-Mark

Battery operated marking gun for wireless marking in industrial environments Handheld device with a pistol-shaped handle with a start button integrated in the handle Rubberized front plate for position fixing with V recess Label area 60 x 25 mm Electromagnetic needle assembly with embossing needle made of hard metal. Length 60 mm Embossing up to 62 HRC material hardness possible Max. 5 mm height compensation, depending on the embossing force Noise level 76 dB (measured at medium embossing force and speed on sheet steel) Weight 3.2 kg, power 40 watts Battery life 1 to 4 hours Batteries 2 pieces (18V, 3.0AH, Li-ion), quick charge batteries, quick charger (approx. 1 hour) integrated control unit Integrated membrane keyboard, high-resolution color display (240x320 pixels) USB / Mini USB interface to the PC, data, updates 100 MB memory Embossing logos (PC software for logo creation available separately) Preview and simulation of the embossing Delivery in a practical transport case

Bar-Code-Lesesystem 2d Bluetooth

2290076 wireless transmission via Bluetooth reads 1D and 2D codes with lighting including dongle Color: Black +DL-AMA-42503 Scanner USB Netzteil +SW-000120 Programmierung BCR USB-Variable BCR e1/e10 The content is transferred to the variable "BCR" of our controller. Attention! The scanner cannot then be operated on another controller or PC.

Needle Assembly E1 / E9 80mm / 90 °

4300434 includes: 3200009A solenoid 1120013 embossing needle 60 mm / 90 ° 2120006 needle spring 1120047 coil core 1120174 guide sleeve

Dl-Ama-42503

48477699 Scanner USB power supply

E10-P123-40

Needle marking system e10-p123-40 For the efficient and permanent labeling of your products of all kinds made of metal, plastic, wood, etc. The marking system is characterized above all by its robust and industrial design according to the following specification: Marking head Hand tool with handle in pistol shape X-axis with linear guide and ball-bearing slide, drive via Rack, Y-axis swivel drive via rack rubberized front plate for position fixation with V recess and Quick setting for workpiece distance Labeling area 120 x 40 mm, LED lighting Electromagnetic needle drive with needle guide and 100 mm marking needle made of hard metal Embossing up to 62 HRC material hardness possible max. 5 mm height adjustment, depending on the embossing force Noise development 76 dB (measured at medium stamping force and speed on sheet steel) 7.5 m control cable to the control unit with cable bend protection Weight 3.7 kg Control unit Integrated membrane keyboard, high-resolution color display (480x272 pixels) USB interface, special USB driver is required RS 232 and RS 422 interface Ethernet and gateway for Profibus optional Signal exchange via potential-free contacts, start / stop unit Weight 5.0 kg software Font height adjustable from 0.5 to 25 mm Dot matrix: 5x7 and 9x13 points per character, variably adjustable point spacings from 0.05 to 1.0 mm linear, circular and angular labeling Multi-line labeling possible in an embossing file inverted and mirror writing Fonts OCR, OCR-A, Arial and Courier Serial numbers in ascending and descending order, time variables, shifts Data Matrix marking (ECC200), Embossing of logos (PC software for logo creation available separately) Preview and simulation of the embossing up to 2000 embossed files programmable Call of 63 programmed files BCD coded Serial communication in ASCII protocol, text protocol and binary protocol

DL-IMW-0001 (Optional)

magnetic faceplate p123-40 Complete bracket for mounting on the pistol p123-40 Holding by 5 permanent magnets (optionally expandable to 10 pieces) Hard anodized surface ATTENTION! Cannot be used with transport trolleys 4400248 + 4400251!

E-MARK-XL (Alternativ)

E-Mark -XL Battery operated marking gun in XL format Hand-held device with a pistol-shaped handle with a start button integrated in the handle Rubberized front plate for position fixation with V recess Labeling area 120 x 40 mm Electromagnetic needle assembly with marking needle made of hard metal, length 100 mm Embossing up to 62 HRC material hardness possible max. 5 mm height adjustment, depending on the embossing force Noise development 76 dB (measured at medium stamping force and speed on sheet steel) Weight 3.6 kg, power 100 watts Battery life 1 to 4 hours, batteries 2 pieces (18V, 3.0AH, Li-ion), quick-charge batteries Quick charger (approx. 1 hour) integrated control unit Integrated membrane keyboard, high-resolution color display (240x320 pixels) USB / Mini USB interface to the PC, data, updates Memory 100 MB software Adjustable font height linear, circular and angular labeling Multi-line labeling possible in an embossing file inverted and mirror writing Different fonts Serial numbers in ascending and descending order, time variables, shifts Data Matrix marking (ECC200), Embossing of logos (PC software for logo creation available separately) Preview and simulation of the embossing Delivery in a practical transport case!

Sic Marking

Sic Marking

3200010

Louvred Solenoid Assembly
