GFLA009028405

GFLA009028405

Johnson Fluiten

Teslimat Seçenekleri
info@yursat.com.tr
Ücretsiz teslimat (Kapı Teslim)
Tedarik süreci min. 3-4 hafta
yurtiçi kargo

Johnson Fluiten ürünlerini Türkiye genelinde kapı teslimi olarak satın almak istiyorsanız, lütfen talebinizle ilgili ürün kodları ve miktarı içeren bilgileri, iletişim bilgilerinizle birlikte info@yursat.com.tr adresimize gönderiniz. Ekibimiz en kısa sürede sizlere satış teklifi sunacaktır.
GFLA009028405 ve diğer modellerimizi içeren geniş ürün portföyümüzü görmek için aşağıdaki listeyi kontrol edebilirsiniz. Eğer ihtiyacınız olan ürünü bulamıyorsanız, lütfen bizimle iletişime geçmekten çekinmeyin, yeni talebinizi mail gönderebilir ya da Teklif İste formunu doldurabilirsiniz.

Firmamız, Johnson Fluiten Türkiye Distribütörü veya temsilcisi değildir. Firmamız sipariş durumunda, belirtilen ürünlerde sadece Orjinal ve yeni ürün teklifi sunmaktadır. Bu sitede gösterilen Özel marka adları ve ticari markalar ilgili sahiplerinin mülkiyetindedir.
Model Tanımı

Typ GFLA009028405

Design = 1-channel
Type of suspension = self-supporting
Medium = water / thermal oil / air
Pressure = 80 bar
Temperature = 90°C
Nipple material = corrosion resistant
Medium connection M = 0.38" BSP (ISO 228)
Machine connection M16*1.5-A left-hand thread
Seal pairing: carbon graphite versus silicon carbide

Tüm Modeller (Johnson Fluiten)
Johnson Fluiten 2 "seal head type R050B3F1R Country of origin: IT Customs tariff number: 84842000 Weight / piece: 6.6 KG Type = 2-channel Type of inner tube = stationary Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 120 ° C Seal head size = 2.00 " Size & type of rotor = 2.00 "BSP (ISO 228) RH Nipple material = corrosion-resistant Medium connection M = 2.00 "BSP (ISO 228) RH Medium connection P = 1.25 "BSP (ISO 228) RH Inner pipe connection S = 1.00 "BSP (ISO 228) RH for standing Inner tube Sealing ring material = B3 = compact mechanical seal made of Silicon carbide versus carbon graphite, Secondary seal Viton®
R050021182

Johnson Fluiten 2 "seal head type R050B3F1R Country of origin: IT Customs tariff number: 84842000 Weight / piece: 6.6 KG Type = 2-channel Type of inner tube = stationary Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 120 ° C Seal head size = 2.00 " Size & type of rotor = 2.00 "BSP (ISO 228) RH Nipple material = corrosion-resistant Medium connection M = 2.00 "BSP (ISO 228) RH Medium connection P = 1.25 "BSP (ISO 228) RH Inner pipe connection S = 1.00 "BSP (ISO 228) RH for standing Inner tube Sealing ring material = B3 = compact mechanical seal made of Silicon carbide versus carbon graphite, Secondary seal Viton®

Johnson Fluiten rotating union type GXA009013983 Country of origin: IT Customs tariff number: 84842000 Weight / piece: 0.6 KG Delivery time: 5 working days Type of suspension = self-supporting Medium = coolant Pressure = 70 BARG Temperature = 120 ° C Seal head size = 0.375 " Nipple material = stainless steel Medium connection M = 0.375 "BSP RH
GXA009013983

Johnson Fluiten rotating union type GXA009013983 Country of origin: IT Customs tariff number: 84842000 Weight / piece: 0.6 KG Delivery time: 5 working days Type of suspension = self-supporting Medium = coolant Pressure = 70 BARG Temperature = 120 ° C Seal head size = 0.375 " Nipple material = stainless steel Medium connection M = 0.375 "BSP RH

Johnson Fluiten rotating union type GFLA009028405 Country of origin: IT Customs tariff number: 84842000 Weight / piece: 0.5 KG Design = 1-channel Type of suspension = self-supporting Medium = water / thermal oil / air Pressure = 80 bar Temperature = 90 ° C Nipple material = corrosion-resistant Medium connection M = 0.38 "BSP (ISO 228) Machine connection M16 * 1.5-A left-hand thread Sealing pairing: carbon graphite against silicon carbide
GFLA009028405

Johnson Fluiten rotating union type GFLA009028405 Country of origin: IT Customs tariff number: 84842000 Weight / piece: 0.5 KG Design = 1-channel Type of suspension = self-supporting Medium = water / thermal oil / air Pressure = 80 bar Temperature = 90 ° C Nipple material = corrosion-resistant Medium connection M = 0.38 "BSP (ISO 228) Machine connection M16 * 1.5-A left-hand thread Sealing pairing: carbon graphite against silicon carbide

Johnson-Fluiten 1.5 "sealing head type RH038B4M1J Country of origin: IT Customs tariff number: 84842000 Weight / piece: 3 KG Design = 1-channel Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 180 C Seal head size = 1.50 " Size & type of rotor = 1.50 "Q-nipple flange connection (without Q flange) Nipple material = corrosion-resistant Medium connection M = 1.50 "BSP (ISO 228) RH Sealing ring material = B4 compact mechanical seal Silicon carbide versus antimony carbon graphite, Secondary waterproofing: AFLAS®
RH038020678

Johnson-Fluiten 1.5 "sealing head type RH038B4M1J Country of origin: IT Customs tariff number: 84842000 Weight / piece: 3 KG Design = 1-channel Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 180 C Seal head size = 1.50 " Size & type of rotor = 1.50 "Q-nipple flange connection (without Q flange) Nipple material = corrosion-resistant Medium connection M = 1.50 "BSP (ISO 228) RH Sealing ring material = B4 compact mechanical seal Silicon carbide versus antimony carbon graphite, Secondary waterproofing: AFLAS®

Johnson Fluiten 1 "seal head type R025B3F1R Type = 2-channel Type of inner tube = stationary Type of suspension = self-supporting Medium = water, thermal oil Temperature = 120 ° C Sealing head size = 1.00 " Size u. Type of rotor = 1.00 "BSP (ISO 228) RH Nipple material = corrosion resistant Medium connection M = 1.00 "BSP (ISO 228) RH Medium connection P = 0.50 "BSP (ISO 228) RH Inner pipe connection S = 0.38 "BSP (ISO 228) RH for standing inner tube Sealing ring material = B3 = compact mechanical seal made Silicon carbide against carbon graphite, Secondary sealing: Viton® Net weight / piece: about 2,400 kg Country of origin: EU / Italy Tariff No .: 84849000
R025009768

Johnson Fluiten 1 "seal head type R025B3F1R Type = 2-channel Type of inner tube = stationary Type of suspension = self-supporting Medium = water, thermal oil Temperature = 120 ° C Sealing head size = 1.00 " Size u. Type of rotor = 1.00 "BSP (ISO 228) RH Nipple material = corrosion resistant Medium connection M = 1.00 "BSP (ISO 228) RH Medium connection P = 0.50 "BSP (ISO 228) RH Inner pipe connection S = 0.38 "BSP (ISO 228) RH for standing inner tube Sealing ring material = B3 = compact mechanical seal made Silicon carbide against carbon graphite, Secondary sealing: Viton® Net weight / piece: about 2,400 kg Country of origin: EU / Italy Tariff No .: 84849000

Johnson Fluiten rotary inlet type GFR009033369 Customs tariff number: 84849000 Machine connection M16 * 1.5 Medium connection 3/8 "NPT Net weight 0,500kg Country of origin: EU / Italy Tariff No .: 84849000
Gfr009033369

Johnson Fluiten rotary inlet type GFR009033369 Customs tariff number: 84849000 Machine connection M16 * 1.5 Medium connection 3/8 "NPT Net weight 0,500kg Country of origin: EU / Italy Tariff No .: 84849000

UNION GFLA009 M3SWC433Z12U31G Type = 1-channel Type of inner tube = None Type of suspension = self-supporting Pressure = 80 bar, temperature = 90 ° C Size u. Type of rotor = M16x1.5 LH Nipple material = corrosion resistant Medium connection M = 0.38 "BSP (ISO 228) Surface treatment = without surface treatment Sealing ring material = Z12 / U31 Ursprungsland: IT Zolltarifnummer: 84849000
Gfla009028405

UNION GFLA009 M3SWC433Z12U31G Type = 1-channel Type of inner tube = None Type of suspension = self-supporting Pressure = 80 bar, temperature = 90 ° C Size u. Type of rotor = M16x1.5 LH Nipple material = corrosion resistant Medium connection M = 0.38 "BSP (ISO 228) Surface treatment = without surface treatment Sealing ring material = Z12 / U31 Ursprungsland: IT Zolltarifnummer: 84849000

Johnson-Fluiten 1.5 "seal head type R038B3L1R Customs tariff number: 84849000 Type = 2-channel Type of inner tube = rotating Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 120 ° C Sealing head size = 1.50 " Size u. Type of rotor = 1.50 "BSP (ISO 228) RH Nipple material = corrosion resistant Medium connection M = 1.50 "BSP (ISO 228) RH Medium connection P = 0.75 "BSP (ISO 228) RH Inner pipe connection S = 26.00 MM for rotating inner pipe Sealing ring material = B3 = compact mechanical seal made Silicon carbide against carbon graphite, Secondary sealing: Viton® Origin: EU / IT Net weight / piece: approx. 4.30 - 4.90kg Stat. Goods no. 84849000
R038020631

Johnson-Fluiten 1.5 "seal head type R038B3L1R Customs tariff number: 84849000 Type = 2-channel Type of inner tube = rotating Type of suspension = self-supporting Medium = water, thermal oil, air Pressure = 35 BARG Temperature = 120 ° C Sealing head size = 1.50 " Size u. Type of rotor = 1.50 "BSP (ISO 228) RH Nipple material = corrosion resistant Medium connection M = 1.50 "BSP (ISO 228) RH Medium connection P = 0.75 "BSP (ISO 228) RH Inner pipe connection S = 26.00 MM for rotating inner pipe Sealing ring material = B3 = compact mechanical seal made Silicon carbide against carbon graphite, Secondary sealing: Viton® Origin: EU / IT Net weight / piece: approx. 4.30 - 4.90kg Stat. Goods no. 84849000

UNION
R019003061

UNION

Johnson Fluiten 3 "seal head type R076B3L1R Type = 2-channel Type of inner tube = rotating Type of suspension = self-supporting Medium = water, air Pressure = 25 BARG Temperature = 120 ° C Seal head size = 3.00 " Size & type of rotor = 3.00 "BSP (ISO 228) RH Medium connection M = 2.00 "BSP (ISO 228) RH Medium connection P = 2.00 "BSP (ISO 228) RH Inner pipe connection S = 60mm for rotating inner pipe Surface treatment = corrosion and wear protection Sealing ring material = B3 compact mechanical seal Silicon carbide against carbon graphite, secondary seal: Viton® Net weight / piece: approx. 32,500 kg Origin: EU / Italy Stat. Item number: 84842000
R076022913

Johnson Fluiten 3 "seal head type R076B3L1R Type = 2-channel Type of inner tube = rotating Type of suspension = self-supporting Medium = water, air Pressure = 25 BARG Temperature = 120 ° C Seal head size = 3.00 " Size & type of rotor = 3.00 "BSP (ISO 228) RH Medium connection M = 2.00 "BSP (ISO 228) RH Medium connection P = 2.00 "BSP (ISO 228) RH Inner pipe connection S = 60mm for rotating inner pipe Surface treatment = corrosion and wear protection Sealing ring material = B3 compact mechanical seal Silicon carbide against carbon graphite, secondary seal: Viton® Net weight / piece: approx. 32,500 kg Origin: EU / Italy Stat. Item number: 84842000
